Estimated Lead Time: 4 -6 Weeks

VE4020S1038

Solenoid valveEVI sm 20.3 360mb 220-240v

VE4000 Series

SAFETY RELIEF SOLENOID VALVE VE4000S1/2

The VE4000S1 and VE4000S2 Series safety relief solenoid

valves are used for safety and control of gaseous fluids in gas

power burners, atmospheric gas boilers, melting furnaces,

incinerators and other gas consuming appliances.

Normally Open valve.

(spring loaded valve disc, opened when de--energized)

Non regulated ON/OFF.

Closed Position Indication switch (optional for VE4000S1).

Opening/closing time: <1 sec.

Maximum working frequency: 20 cycles/min.

Wrench boss as well on inlet side as on outlet side for

pipe fitting incorporated in the valve housing.

2 Auxiliary pressure taps with Rp 1/4??threaded

connections, both on the inlet pressure side.

Coil field replaceable.

Coil suitable for permanent energization.

Coil turnable over 360_.

Internal fine mesh screen

Models: VE4000S1, without Closed Position Indication (CPI) switch VE4000S2, with CPI switch

Pipe sizes: Inlet and outlet 3/4??and 1??internal parallel pipe thread according to ISO 7--1. The valve may be assembled on the pipeline within plus or minus 90 degrees

of the vertical axis and 30 cm. air space around the coil assy.

Maximum operating pressure: 200 or 360 mbar Torsion and bending stress Pipe connections meet group 2, according to EN161 requirements

_Shipping Weight: 3 kg
