Estimated Lead Time : 6-8 Weeks
Manufacturer : Honeywell
STG77L-E1G000-1-0-CHC-11C-B-20A0-F1-0000
Gauge In-Line/URL/Max Span : 3000 (210)
LRL : -14.7 (-1.0)
Min Span : 30(2.1)
Units : psi (bar)
Process Head / Reference Head Material :316 Stainless Steel / 316 Stainless Steel
Barrier Diaphragm Material : 316L SS
Fill Fluid : Silicone Oil 200
Process Connection :
Size/Type : 1/2" NPT (female)
Material : Same as Process Head 1a
Bolt/Nuts Materials : None
Vent/Drain Type/Location : None
Head Type : None
Material : None
Gasket Materials : None
Meter Body & Connection Orientation
Standard : High Side Left, Low Side Right2 / Std Head Orientation
AGENCY APPROVALS : No Approvals Required
Electronic Housing Material & Connection Type
Material : Polyester Powder Coated Aluminum
Connection : 1/2 NPT
Lightning Protection : Yes
Analog Output : 4-20mA dc
Digital Protocol : HART Protocol
Customer Interface Selections
Indicator: Basic
Ext Zero, Span & Config Buttons : Yes
Languages : EN
Application Software: Standard Diagnostics
Output Limit, Failsafe & Write Protect Settings
Write Protect : Disabled
Fail Mode : High> 21.0mAdc
High & Low Output Limits : Honeywell Std (3.8 - 20.8 mAdc)
General Configuration : Custom Configuration (Unit Data Required from customer)
Accuracy and Calibration
Accuracy : Standard
Calibration Qty : Single Calibration
Calibrated Range : Custom (Unit Data Required)
Mounting Bracket
Bracket Type : Angle Bracket
Material : 304 SS
Customer Tag Type : No customer tag
Unassembled Conduit Plugs & Adapters : No Conduit Plugs or Adapters Required
Certifications & Warranty : Calibration Test Report & Certificate of Conformance (F3399)
Manufacturing Specials : Factory Identification
Shipping Weight : 4 Kg

Item Number:STG77L-E1G000-1-0-CHC-11C-B-20A0-F1-0000
