• Estimated Lead Time : 1 weeks. \n
• Manufacturer : STG74S-E1G000-1-0-AHS-11C-B-11A0-F1-0000 \n
• Product No. :__oneywell \n
• Product type : STG700 Gauge Pressure Transmitters \n
• Gauge In-Line : URL/Max Span = 500 (35), LRL = 14.7 (-1.0), M in span = 5 (.35), Units = psi (bar). \n
• E : Process Head & Diaphragm Materials**=** 316 Stainless Steel , 316L SS \n
• 1 : Fill Fluid = Silicone Oil 200 \n
• G : Process Connection = 1/2" NPT (female), Material same as Process Head \n
• 0 : Bolt/Nut Materials = None \n
• 0 : Vent/Drain Type/Location : None \n
• 0 : Gasket Material = None \n
• 1 : Head/Connect Orientation = Standard, High Side Left, Ref Side Right2 / Std Head Orientation \n
• 0 : Approvals = No Approvals Required \n
• A : Electronic Housing Material & Connection Type = Polyester Powder Coated Aluminum, 1/2 NPT \n
• H : Output/ Protocol = 4-20mA dc, HART Protocol \n
• S : Indicator = Standard (w/Internal Zero,Span&Config buttons), Ext Zero, Span & Config Buttons = None, Languages = English. \n
• 1 : Application Software = Standard Diagnostics \n
• 1 : Write Protect = Disabled, Fail Mode = High> 21.0mAdc, High & Low Output Limits = Honeywell Std (3.8 - 20.8 mAdc). \n
• C : General Configuration = Custom Configuration (Unit Data Required from customer) \n
• B : Accuracy = standard, Calibrated Range = Custom (Unit Data Required), Calibration Qty = Single Calibration \n
• 1 : Mounting Bracket = Angle Bracket, Carbon steel \n
• 1 : Customer Tag = One Wired Stainless Steel Tag (Up to 4 lines 26 char/line) \n
• A0 : Unassembled Conduit Plugs & Adapters = No Conduit Plugs or Adapters Required \n
• F1 : Certifications & Warranty = Calibration Test Report & Certificate of Conformance \n
• 0000 : Factory = Factory Identification \n
• Shipping Weight : 4 Kg \n
