Estimated Lead Time : 6 - 8 weeks.
Manufacturer : Honeywell
Product No. : STG74S-E1G000-1-0-AHS-11C-B
Product type : STG700 SmartLine Gauge Pressure Transmitter
Gauge In-Line : STG74S - URL/Max span= 500 (35), LRL = -14.7 (-1.0), Min Span = 5 (.35), Units = psi (bar).
Process Heads & Diaphragm Materials : E = 316 Stainless Steel , 316L SS
Fill Fluid : 1 = Silicone Oil 200
Process Connection : G = 1/2" NPT (female), Material same as Process Head
Bolt/Nut Materials : 0 = None
Vent/Drain Type/Location : 0 = None
Gasket Material : 0 = None
Head/Connect Orientation : 1 = Standard, High Side Left, Low Side Right2 / Std Head Orientation
Approvals: 0 = No approvals required
Electronic Housing Material & Connection Type : A = Polyester Powder Coated Aluminium, 1/2NPT.
Output/ Protocol : H = Analog Output : 4-20mA dc, Digital Protocol : HART Protocol.
Customer Interface Selections : S = Indicator : Standard (w/internal Zero,Span & Config Buttons), language : english.
Application Software : 1 = Standard diagnostic
Output Limit, Failsafe & Write Protect Settings : 1 = Write Protect : Disabled, Fail Mode : High> 21.0mAdc, High & Low Output Limits : Honeywell Std (3.8 - 20.8 mAdc)
General Configuration : C = Custom Configuration (Unit Data Required from customer)
Accuracy and Calibration : B = Accuracy : Standard, Calibrated range : Custom (Unit Data Required), Calibration Qty : Single Calibration.
Dimensions (HxWxD), approx : 18.23 cm X 12.59 cm X 11cm
Weight : 2kg
Shipping Weight : 4 Kg
