- Estimated Lead Time : 1 - 2 days. \n
- Manufacturer : Honeywell \n
- Product No. :__TD725-E1HS1AS-1-C-BHS-11C-B-00A0-F1 \n
- Product type : STD700 Differential Pressure Transmitter \n
- STD725 : Measurement Range = 400/(1000) URL, -400/(-1000) LRL, 400/(1000) Max span, 4.0 (10) min span, " H2O (mbar) units. \n
- E = 316 Stainless Steel Process Head Material , 316L Stainless Steel Diaphragm Material. \n
- Fill Fluid : 1 = Silicone Oil 200 \n
- Process Connection : H = 1/2" NPT female, Materials to Match Head & Head Bolt Materials Selections \n
- Bolt/Nut Materials : S = 316 SS \n
- Vent/Drain Type/Location : 1 = Single Ended Head Type \n
- Gasket Material : A = Teflon鎼 or PTFE (Glass Filled) \n
- Static Pressure : S = Standard Static Pressure - 4500 psig (315 bar) \n
- Head/Connect Orientation : 1 = Standard, High Side Left, Low Side Right2 / Std Head Orientation \n
- Approvals : C = ATEX Explosion proof, Intrinsically Safe & Non-incendive \n
- Electronic Housing Material & Connection Type : B = Polyester Powder Coated Aluminium material, M20 material. \n
- Output/ Protocol : H = 4-20mA dc analog output, HART Protocol Digital Protocol. \n
- Customer Interface Selections : S = Standard (w/Internal Zero,Span & Config Buttons), English. \n
- Application Software : 1 = Standard Diagnostics \n
- Output Limit, Failsafe & Write Protect Setting : 1 = Disabled Write Protect, High> 21.0mAdc fail mode, Honeywell Std (3.8 - 20.8 mAdc) High & Low Output Limits. \n
- General Configuration : C = Custom Configuration (Unit Data Required from customer) \n
- Accuracy and Calibration : B = Standard Accuracy, Custom (Unit Data Required) Calibrated Range, Single Calibration \n
- Mounting Bracket : 0 = None \n
- Customer Tag : 0 = No customer tag \n
- Unassembled Conduit Plugs & Adapters : A0 = No Conduit Plugs or Adapters Required \n
- Certifications & Warranty : F1 = Calibration Test Report & Certificate of Conformance \n
- Shipping Weight : 6 Kg \n
