- Estimated Lead Time : 2 - 4 days. \n
- Manufacturer : STD725-E1AC4AS-1-0-AHS-11C-B-11A0-F1-0000 \n
- Product No. :__oneywell \n
- Product type : STD700 Differential Pressure Transmitter \n
- Measurement Range : 400/(1000) URL, -400/(-1000) LRL, 400/(1000) Max span, 4.0 (10) Min span, H2O (mbar) units. \n
- E : Process Head Material = 316 Stainless Steel, Diaphragm Material = 316L Stainless Steel. \n
- 1 : Fill Fluid = Silicone Oil 200 \n
- A : Process Connection = None, None (1/4" NPTF female thread Std) \n
- C : Bolt/Nut Materials = Carbon Steel \n
- 4 : Head type = Dual Ended, Vent Type = Standard Vent, Location = End, Vent Material = Matches Head Material \n
- A : Gasket Material = Teflon鎼 or PTFE (Glass Filled) \n
- S : Static Pressure = Standard Static Pressure - 4500 psig (315 bar) \n
- 1 : Head/Connect Orientation = Standard, High Side Left, Low Side Right2 / Std Head Orientation \n
- 0 : Approvals = No Approvals Required \n
- A : Electronic Housing Material & Connection Type = Polyester Powder Coated Aluminum, 1/2 NPT \n
- H : Output/ Protocol = 4-20mA dc, HART Protocol \n
- S : Indicator = Zero,Span & Config Buttons), Ext Zero, Span & Config Buttons = None, Languages = English. \n
- 1 : Application Software = Standard Diagnostics \n
- 1 : Write Protect = Disabled, Fail Mode = High> 21.0mAdc, High & Low Output Limits = Honeywell Std (3.8 - 20.8 mAdc). \n
- C : General Configuration = Custom Configuration (Unit Data Required from customer) \n
- B : Accuracy = standard, Calibrated Range = Custom (Unit Data Required), Calibration Qty = Single Calibration \n
- 1 : Mounting Bracket = Angle Bracket, Carbon Steel \n
- 1 : Customer Tag = One Wired Stainless Steel Tag (Up to 4 lines 26 char/line) \n
- A0 : Unassembled Conduit Plugs & Adapters = No Conduit Plugs or Adapters Required \n
- F1 : Certifications & Warranty = Calibration Test Report & Certificate of Conformance \n
- 0000 : Factory = Factory Identification \n
- Shipping Weight : 7 Kg \n
