• Estimated Lead Time : In stock. Usually ships in 7-10 working days. \n
• Manufacturer : Honeywell \n
• Product No. : STD720-H1HC2AS-1-C-CH0-11S-A \n
• Product type : STG700 Gauge Pressure Transmitters \n
• STG770 : STG700 Gauge Dual Head, 3000 (210) URL/max span, -14.7 (-1.0) LRL, 30 (2.1) Min span, psi (bar) \n
• Process Wetted Heads & Diaphragm : H = Tantalum \n
• Fill Fluid : 1 = Silicone Oil 200 \n
• Process Connection : = 1/2" NPT female Materials to Match Head & \n
• Head Bolt Materials Selections \n
• Bolt/Nut Materials : C = Carbon Steel \n
• 2 = Single Ended , Standard Vent , Side , Matches Head Material \n
• Gasket Material : A = Teflon鎼確TFE(Glass Filled) \n
• Static Pressure : S = Standard Static Pressure - 4500 Psig (315 bar) \n
• Head/Connect Orientation : 1 = Standard , High Side Left, Low Side Right2 / Std Head Orientation \n
• Aproval : c = ATEX Explosion proof, Intrinsically Safe & Non-incendive \n
• Electronic Housing Material & Connection Type : C = Polyester Powder Coated Aluminum , 1/2 NPT , Yes \n
• Output/ Protocol : H = 4-20mA dc , HART Protocol \n
• Customer Interface Selections : 0 = None \n
• Application Software : 1 = Standard Diagnostics \n
• Output Limit,Failsafe & Write Protect Settings : 1 = Disable , High>21.0mAdc , Honeywell Std (3.8 - 20.8 mAdc) \n
• General Cnfiguration : S = Factory standard \n
• Accurancy And Calibration : A = Standard , Factory Std , Single Calibration \n
• Shipping Weight : 6 Kg \n
