Newsino Energy Company

Estimated Lead Time : In Stock. Usually Ships In 7-10 Working Days.
Manufacturer: Honeywell_
Sensor Element : Phos-Bronze Bellows_
Overview : Modulating Pressure Operating Control For Regulation Of Liquid Or Air And Other Non-Corrosive Gases._
Pipe Connections, Main Or High Pressure_鍊焈_ : 1/4 In. Npt Internal Thread_
Maximum Sustained Operating Pressure (Psi) : 325 Psi_
Maximum Sustained Operating Pressure (Kpa) : 2241 Kpa_
Application : Modulating Pressure Control For Regulation Of Liquid, Air, Or Other Non-Corrosive Gases.
Pressure Differential (Psi) : 28 To 110 Psi
Pressure Differential (Kpa) : 193 To 758 Kpa
Operating Range (Psi) : 10 To 300 Psi
Operating Range (Kpa) : 0 - 2 Mpa
Mounting : 1/4 In Bsp-Tr Thread Mounting
Switch Operation : Modulating
Dimensions (In.) : 6 1/16 In. High X 4 1/2 In. Wide X 2 3/4 In. Deep
Dimensions (Mm) : 154 Mm High X 114 Mm Wide X 70 Mm Deep
Temperature Range (F) : 32 F To 150 F
Temperature Range (C) : 0 C To 66 C
Electrical Connections : Screw Terminal
Shipping Weight: 3 Kg
